T-wire filter element, also known as Johnson filter element, fully automatic self-cleaning filter element; is made by welding ribs and V-shaped wire on professional special welding equipment. The ribs and V-shaped wire are resistance welded by special equipment. It has high welding strength, uniform gap, strong corrosion resistance, large effective filtration area, good permeability, simple structure, and the gap can reach 20 microns, which can be selected by the user at will.
T-wire filter element
Product introduction:
T-wire filter element, also known as Johnson filter element, fully automatic self-cleaning filter element; is made by welding ribs and V-shaped wire on professional special welding equipment. The ribs and V-shaped wire are resistance welded by special equipment. It has high welding strength, uniform gap, strong corrosion resistance, large effective filtration area, good permeability, simple structure, and the gap can reach 20 microns, which can be selected by the user at will.
Material selection:
Stainless steel 304, 316L, 904L, Hastelloy.
Product Features
1. High mechanical strength, able to withstand large pressure difference;
2. Uniform filter gaps, able to form relatively uniform filter cakes, conducive to backwashing regeneration;
3. Wedge-shaped filter gaps, can improve backwashing regeneration capacity;
4. Pressure-resistant, temperature-resistant, anti-aging, anti-corrosion, suitable for various fluids.
5. T-type wire filter element The filter element uses a metal wedge-shaped wire mesh (Johnson tube) as a filter element, which has the advantages of high mechanical strength, high pressure difference resistance, easy flushing and regeneration; the nearly two-dimensional filter screen has no dead corners for particle accumulation, and the wedge-shaped gap can gather backwashing energy during backwashing, and the backwashing effect is good.
Application areas: The product is particularly suitable for waxy oil, asphalt, diesel, beer, and oil with high viscosity. It is widely used in coarse filtration and fine filtration projects in water treatment in power chemical industry, natural gas wells, petrochemical industry, chemical mining, papermaking, environmental protection, metallurgy, food, sand control, decoration and other industries.
