The PP series meltblown filter elements are made of pure polypropylene microfibers entangled by hot-melt entanglement without the use of any chemical adhesives. The fibers are randomly bonded together to form a three-dimensional microporous structure. This structure combines surface, depth, and precision filtration. Its deep filtration structure features a sparse exterior and dense interior with a gradually changing pore size, offering strong dirt-holding capacity. Depending on the manufacturing process, the elements are available in five finishes: smooth, fleece, orange peel, fine grain, and grooved. The finish can be selected based on actual use. They are primarily used for particle interception, clarifying filtration, and security filtration. They offer excellent permeability and are relatively economical pre-filter elements.
PP series meltblown filter elements
The PP series meltblown filter elements are made of pure polypropylene microfibers entangled by hot-melt entanglement without the use of any chemical adhesives. The fibers are randomly bonded together to form a three-dimensional microporous structure. This structure combines surface, depth, and precision filtration. Its deep filtration structure features a sparse exterior and dense interior with a gradually changing pore size, offering strong dirt-holding capacity. Depending on the manufacturing process, the elements are available in five finishes: smooth, fleece, orange peel, fine grain, and grooved. The finish can be selected based on actual use. They are primarily used for particle interception, clarifying filtration, and security filtration. They offer excellent permeability and are relatively economical pre-filter elements.
Product Series and Features and Benefits
Smooth surface (DLPP) : Smooth surface, no fiber shedding, gradient pore size (basic type)
Drain groove (DG) :Grooved surface increases effective filtration area, high flux, and high dirt holding capacity
Fine grain (MG) : Densely packed fibers, up to 99% retention rate
Orange peel (H): Fine and compact, high mechanical strength, high pressure resistance, no shedding
Fleece (P): Surface entangled filament polypropylene fibers, no shedding, ultra-high dirt holding capacity
Specifications
Dimensions :
25mm (Inner 15mm)
43mm (Inner 20mm)
63mm (Inner 28mm, 30mm)
110mm (Inner 28mm)
115mm (Inner 28mm)
Length : 9.75",9.87 ,10"20",30",40
Materials of Construction
Filter Media :Polypropylene (PP)
End Caps :Polypropylene (PP)
Gaskets/Seals :Silicone Rubber, EPDM, NBR, Fluororubber
Center Rod : Polypropylene (PP)
Product performance
Maximum Operating Temperature :65°C
Maximum Pressure Differential: 2.0 Bar, 21°C
Application areas
RO reverse osmosis systems, security filtration; domestic drinking water filtration; industrial water and electroplating solution filtration; chemical raw material and organic solvent filtration; acid and alkaline liquid filtration in industrial and chemical manufacturing processes
